Sketching

Create and edit a 2D sketch curve. A sketch curve is any "wire" entity such as a line, rectangle, circle, or arc.

Point/Line
Sketch and edit a point, line, polyline, or line-arc.
Rectangles
Sketch and edit a rectangle.
Polygons
Sketch and edit a parallelogram or a regular polygon.
Circles
Sketch and edit a circle.
Arcs
Sketch and edit an arc.
Ellipses
Sketch and edit an ellipse or an elliptical arc.
Splines
Sketch and edit a spline.
Trim/Divide
Trim or divide a sketch curve.
Offset/Mirror
Offset or mirror a sketch curve.
Extend
Extend or shorten an entity of a sketch curve.
Fillet
Round the corners of 2D sketch curves to create fillets with the same radius or different radii.
Import Entities
Import geometry that was not created using a sketching tool by projecting it onto a sketch plane as construction geometry.
Dimension
Apply and edit a dimensional constraint to control the size and proportions of a sketch. You can make a dimension "driven" so that it's a regular dimension, not a constraint.
Set Sketch Plane
Change the sketch plane of an existing sketch curve.
Image Plane
Create an image plane that you can use as a background reference image, so you can trace lines and curves to start your design.
Sketch Constraints
Apply geometric relationships such as tangency and perpendicularity to sketch curves.
