WindowFcn

Filter

Select a window type:

Structure

Filter/Rectangular

Rectangular

Known also as the Dirichlet window, it is the simplest window function.
w(n)=1
for n=0:N-1

Number

0
1

Filter/Triangular

Triangular

Triangular windows is defined as follows:
If the symmetric option is chosen:
w(n)=1 - \left|\frac{n-\frac{N-1}{2}}{\frac{N+1}{2}}\right|,
If the periodic option is chosen:
w(n)=1 - \left|\frac{n-\frac{N}{2}}{\frac{N+2}{2}}\right|,
for n=0:N-1

Number

0
1

Filter/Chebyshev

Chebyshev

See the Chebyshev documentation in the OML Guide.

Number

0
1

Filter/Welch

Welch

Number

0
1

Filter/Hamming

Hamming

Number

0
1

Filter/Hann

Hann

Number

0
1

Filter/Blackman

Blackman

Number

0
1

Filter/Parzen

Parzen

Number

0
1

Filter/KaiserBessel

KaiserBessel

Number

0
1

Chebyshev_p

Chebyshev filter parameters

Structure

Chebyshev_p/sidelobe

sidelobe(=-20*Alpha)

cell of matrices of size 1x1

kaiserbessel_p

Kaiser-Bessel filter parameter

Structure

kaiserbessel_p/alpha

Alpha>=0

cell of matrices of size 1x1

wtype

Filter type

String

'symmetric'
'periodic'

externalActivation

External activation

Number

0
1
